Complete Bhs Corrugating Line, 2500Mm / 98", Lhdpg, B, C And E Flute

We present this complete BHS corrugating Line, 2500mm / 98", LHDPG, manufactured in 1999.

The corrugator is in very good condition, can be inspected in production at any time and is available in March 2026.

General Information:

• Working Width: 2500mm / 98"
• LHDPG
• Wet End: Duplex
• Dry End: Duplex
• Corrugating Rolls:
  • Modul Facer 1: B and E flute
  • Modul Facer 2: C and B Flute
• control: S5

SOUNDPROOF CABINS NOT INCLUDED

Machinery Details:

WET END

• 5 BHS Rollstands (3 Liner / 2 Fluting), year 1999

  • equipped with RE-brakes and hydraulic lifting system

• 5 BHS ARW-M 500 Splicer (3 Liner / 2 Fluting), year 1999

  • integrated pendular roll and rest roll computer
  • web tension control

• Modulfacer MF-B II

  • C and B Flute
  • pressure belt technology
  • inernal pivoting flute change system
  • peripheral heated corrugating rolls
  • automatic glue level control
  • integrated preheater, diameter 600mm / 24"
  • external simplex preheater, diameter 1100mm / 43"
  • integrated preconditioner, diameter 600mm / 24"
  • Upgrades: parallel operating panel (2016), main drive (2023)

• Modul facer MF-B II

  • B and E Flute
  • pressure belt technology
  • inernal pivoting flute change system
  • peripheral heated corrugating rolls
  • automatic glue dams and glue level control
  • integrated preheater, diameter 600mm / 24"
  • external simplex preheater, diameter 1100mm / 43"
  • integrated preconditioner, diameter 600mm / 24"
  • infeed steam pressure control
  • Upgrade: parallel operating panel (2016)

• Triplex Preheater, VZR 1100/3

  • 3 heating drums, diameter 1100mm / 43"
  • external heating drum, diameter 900mm / 35.5"
  • automatic web arms
  • motorized drum rotation
  • zero wrap

• Glue Unit LWR/2

  • automatic glue dam and glue level control
  • Duplex Bridge with bridge level control and bridge brake system

• Double Backer

  • 22 cast iron hot plates
  • Bartrol shoe system
  • automatic pressure load program
  • integrated preheater for Liner Infeed
  • Upgrade: 2023 DC main drive

DRY END

• Rotary Shear KQ-M

  • Steel Knife bars
  • pneumativ waste flap

• Copar Line following system, year 2008

• Slitter Scorer SR-A M

  • RRMM
  • Swing Change
  • 7 Outs
  • Disc Cut Slotting System
  • 2x8 pairs of scorers at each section

• Rotary Shear KQ-F

• Web Diverter and Cut To Mark Station

• Cut Off HQ-M/2

  • Carbon fibre knife bars

• Double Stacker, AAR/2

  • stacking height upstacker and downstacker: 2000mm / 78.75"
  • stacking length upstacker: 4500mm / 177"
  • stacking length downstacker: 3600mm / 142"
